Overview
INFINITY LOOP COOLING
The Matrix name is reserved for exceptional products that leap forward, exceeding innovation and performance expectations. The ROG Matrix GeForce RTX™ 2080 Ti is the latest graphics card to earn this pedigree by introducing Infinity Loop, a unique all-in-one closed-loop cooling system. Each card has been binned and tuned to deliver the best out-of-the-box Turing™ experience, raising the bar for graphics horsepower in small chassis and air-cooled builds.
Deep dive
With pump, tubing, and radiator integrated seamlessly under the shroud, the Matrix is cooler and quieter than air-cooled cards while taking up the same amount of space. An oversized heat spreader covers the GPU die and RAM to ensure the most critical components are kept cool. To top it all off, we included three of our industry-leading Axial-tech fans to push cool air through the radiator while simultaneously cooling the VRMs.
Harness the hardware
Hardware isn’t the only area where research and development is being applied to take things to the next level. The ROG team has been building up the GPU Tweak II software utility to offer unique features along with the standard monitoring, tweaking, and tuning you would expect. Like all of our premium graphics cards, the ROG Matrix GeForce RTX™ 2080 Ti is bundled with XSplit streaming software and wtfast’s Gamers Private Network to make sure that your online experience is the best it can be.
Specification
| Connectors | 2x HDMI 2.0b, 2x DisplayPort 1.4a, 1x USB-C with DisplayPort 1.4a |
|---|---|
| Model | NVIDIA GeForce RTX 2080 Ti (Desktop) |
| Chip | TU102-300X-K1-A1 “Turing” |
| Manufacturing process | 12nm (TSMC) |
| Chip clock | 1350MHz, Boost: 1815MHz (OC Mode) |
| Memory | 11GB GDDR6, 1850MHz, 352bit, 651GB/s |
| Shader Units/TMUs/ROPs | 4352/272/88 |
| TDP | 250W (NVIDIA) |
| External power supply | 2x 8-Pin PCIe |
| Cooling | 3x Axial-fan (90mm), closed water cooling kit without external radiator |
| Total height | triple-slot |
| Dimensions | 310x135x60mm |
| Special features | Real-Time Ray Tracing (10GRays/s), Raytracing Cores (68), Tensor Cores (544), H.265 encode/decode, NVIDIA G-Sync, NVIDIA VR-Ready, NVIDIA NVLink, NVIDIA 2-Way SLI (NVLink), HDCP 2.2, 0dB-zero-fan-mode (up to 55°C), Backplate, LED lighting (RGB), boost clock overclocked (+270MHz) |
| Interface | PCIe 3.0 x16 |
| Computing power | 15798GFLOPS (Single), 494GFLOPS (Double) |
| DirectX | 12.1 |
| OpenGL | 4.6 |
| OpenCL | 2.0 |
| Vulkan | 1.1.103 |
| Shader model | 6.3 |
