Teltonika TRM240 is an Industrial LTE Cat 1 Modem with rugged aluminium housing, USB interface and external antenna for better signal coverage. This modem 4G is backwards compatible with 3G and 2G technologies and is the most cost-efficient option for upgrading existing industrial and public infrastructure with modern M2M connectivity.
The Teltonika modem TRM240 is in a robust aluminum housing and meets the IP30 standard, so it is protected against the intrusion of objects smaller than 2.5 millimeters.
CONNECTIVITY
4G/LTE (Cat 1), 3G, 2G
DURABILITY
Rugged aluminium housing
USB
Interface for internet access
EFFICIENCY
Low power consumption
COMPACTNESS
Small size, easy installation
EASE OF USE
Controlled using Network manager
Specification
| HARDWARE | |
| Mobile | LTE (Cat1) / 3G / 2G |
| SIM slot | Mini SIM (2FF) |
| Antenna connector | 1 x SMA for LTE |
| Operating Voltage | 5V – powered via microUSB |
| Power consumption | 3.2 W Max |
| Configuration interface | microUSB |
| LED indicators | Power, Network and LTE status LEDs |
| Operating temperature | -40 °C to 75 °C |
| Operating humidity | 10 % to 90 % non-condensing |
| Casing material | Aluminium housing |
| Ingress Protection Rating | IP30 |
| Dimensions (W x H x D) | 74.5 x 25 x 64.5 mm |
| Weight | 131 g |
| SOFTWARE | |
| Management software | Windows Connection Manager (NDIS driver) |
| USB Serial Driver | Windows 7/8/8.1/10, Windows CE 5.0/6.0, Linux 2.6/3.x/4.1~4.14, Android 4.x/5.x/6.x/7.x/8.x |
| RIL Driver | Android 4.x/5.x/6.x/7.x/8.x |
| NDIS Driver | Windows 7/8/8.1/10 |
| Gobinet Driver | Linux 2.6/3.x/4.1~4.14 |
| Linux qmi wwan Driver | 3.x (3.4 and later)/4.1~4.14 |
| Protocols | TCP/UDP/PPP/FTP(S)/HTTP(S)/NTP/PING/QMI/SSL |
| INTERFACES | |
| Management interface | AT Commands (3GPP TS27.007, 3GPP TS27.005) Hayes AT Command set Enhanced AT Commands |
