Eaton 5P 650VA / 420W Line Interactive Tower UPS – 5P650AU

The Eaton 5P is a Line interactive, density optimised (up to 1550VA in 1U) power protection for IT & Telecom environment. Wide power management capabilities offering point-to-point and network supervision.

Features:

The graphical LCD display provides clear information on the UPS’s status and measurements on a single screen. Enhanced configuration capabilities are also available with easy-to-use navigation keys.
Meters energy consumption and provides kWH values through the LCD and Intelligent Power Software
Load segment control enables prioritised shutdows of nonessential equipment to maximise battery runtime for critical devices. Load segment control can also be used to remotely reboot locked-up network equipment or to manage scheduled shutdowns and sequential start-ups.
With an optimised electrical design, the 5P can provide a high quality output signal for any sensitive equipment connected, such as active PFC servers.
5P is available as a tower or rack form factor to cater for varied deployment applications
Stronger longer battery life: Eaton ABM battery management technology uses an innovative three-stage charging technique that only recharges the battery when necessary, so the battery experiences less corrosion and service life is prolonged by up to 50%
Batteries can be hot-swapped without ever having to shut down connected equipment. With an optional hot-swap maintenance bypass module, you can even replace the entire UPS.

Ideal for Protecting:

Servers
Switches
Routers
Storage devices

Specifications:

Topology: Line-Interactive High Frequency (Pure Sinewave, Booster + Fader)
Configuration: Tower
Rating: (VA/Watts) 650/420
Connection: (1) Aust. 10A
Input Voltage Without Using Batteries: 160V-294V (adjustable to 150V-294V)
Input frequency Range Without Using Batteries: 47 to 70Hz (50 Hz system), 56.5 to 70Hz (60 Hz system), 40Hz in low-sensitivity mode
Voltages: 230 V (+6/-10 %) (Adjustable to 200V / 220V / 230V / 240V)
Output Receptacles: (3) IEC-320-C13, (2) Aust. 10A
Remotely controlled sockets: 2 groups of 1 x AU (10 A) output receptacles
Output Frequency: 50/60 Hz +/- 0.1 % (autosensing)
Battery Management: ABM & temperature compensated charging method (user selectable), automatic battery test, deep discharge protection
Cold start (No mains power): Yes
User Interface: 3 LEDS + Multilingual LCD : access to measures, alarm messages and customization
Communication Ports: 1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously), 1 mini terminal block for remote ON/OFF and Remote Power Off
Communications Card Slots: 1 slot for Network-MS card, ModBus-MS or Relay-MS cards
Audible Noise: 40 dBA
Operating Temperature: 0 to 35??C
Safety markings: IEC/EN 62040-1
EMC Markings: IEC/EN 62040-2 class B (EMC), IEC/EN 62040-3 (performance), C-Tick
Approvals: CE, CB report
Quality: Designed, manufactured and marketed under ISO9001 & ISO14001 quality system

Package Contents:

5P UPS
Eaton Intelligent Power Software CD
USB cable
Serial cable
Safety guide
Quick start guide
CD with 10-language user manual
