ASUS ROG Maximus XIII Extreme EATX Motherboard, Intel Z590 Chipset, Intel 1200 socket, Max. Memory 128GB, PCI Express 4.0 | 90MB15S0-M0EAY0

ROG Maximus XIII Extreme

Intel Z590 EATX motherboard with 18+2 power stages, five M.2 slots, USB 3.2 Gen 2×2 front-panel connector, USB 3.2 Gen 2 front-panel connector, dual Thunderbolt 4, Marvell AQtion 10 Gb Ethernet, Intel 2.5 Gb Ethernet, PCIe 4.0, onboard WiFi 6E (802.11ax) and Aura Sync RGB lighting

Features:

• Intel Socket LGA 1200 for 11th Gen Intel Core processors and 10th Gen Intel Core, Pentium Gold and Celeron processors
• Intelligent Control: ASUS-exclusive software and firmware utilities that simplify setup and improve performance: AI Overclocking, AI Cooling, AI Networking and Two-Way AI Noise-Cancelation
• Robust Power Solution: 18+2 teamed power stages – each rated at 100 Amps, ProCool II power connectors, MicroFine alloy chokes and 10K Japanese-made black metallic capacitors
• Optimised Thermal Design: Enlarged VRM heatsinks plus integrated aluminium I/O cover, high-conductivity thermal pad, five M.2 heatsinks with embedded backplates and ROG Water-Cooling Zone
• High-Performance Networking: Onboard WiFi 6E (802.11ax), Marvell AQtion 10 Gb Ethernet, Intel 2.5 Gb Ethernet, and ASUS LANGuard
• Fastest Gaming Connectivity: PCIe 4.0, five M.2 slots, USB 3.2 Gen 2×2 front-panel connector, dual Thunderbolt 4 USB-C
• Industry-leading Gaming Audio: ROG SupremeFX ALC4082 with ESS ES9018Q2C DAC for high-fidelity sound
• Unmatched Personalisation: 2” LiveDash OLED,

Teamed Power Architecture Modern CPU architectures up the ante for motherboard power design by transitioning from deep power saving modes to full load almost instantaneously. The latest ROG VRM architecture rises to the challenge by utilizing teamed power stages to rapidly swing current, while maintaining exemplary thermal. Dual 8-Pin ProCool II Power Connectors 18+2 Power Stages MicroFine Alloy Chokes 10K Japanese-Made Black Metallic Capacitors	ASUS OptiMem III With proprietary memory trace layout tweaks that improve signal integrity and mitigate noise, OptiMem III allows memory kits to run at lower latencies and reduced voltages while operating at higher frequencies. Stack ROG Maximus XIII Extreme with your favourite modules and maximise the throughput of the 11th Gen Intel Core Rocket Lake processor for applications that demand massive bandwidth.	Cooler by Design ROG Maximus XIII Extreme features comprehensive cooling options that are configurable via Fan Xpert 4 or the UEFI BIOS. Multiple Temperature Sources 4-pin PWM/DC Fan Headers and ASUS HYDRANODE Bundled ROG Fan Controller

PCIe 4.0-Ready ROG Maximus XIII Extreme is equipped with four onboard M.2 slots, two of which offer PCIe 4.0 support for the latest GPUs and high-speed SSDs.	Intel WiFi 6E (Gig+) Onboard WiFi 6E technology takes advantage of the newly available radio spectrum in the 6 GHz band, providing up to three times the bandwidth of the 5 GHz band and up to seven 160 MHz bands to deliver ultrafast wireless networking speeds along with improved capacity and better performance in dense wireless environments.	USB 3.2 Gen 2 Front-Panel Connectors Two front-panel USB 3.2 connectors are ready to accommodate a wide variety of devices.

ROG Fan Controller The ROG Fan Controller offers additional six headers that can be controlled via FanXpert 4. The card features two temperature-sensor headers, along with two thermistors that can be attached to various components. There are also six ARGB headers to illuminate compatible fans and addressable strips.	SupremeFX ROG SupremeFX audio technology delivers an exceptional 113 dB signal-to-noise ratio on the line-in connection to provide best-ever recording quality. There’s also a low-dropout regulator for clean power delivery to the SupremeFX ALC4082 codec, and an ESS 9018Q2C integrated DAC. Audio Line Shielding ESS SABRE9018Q2C ALC 4082 Codec Switching MOSFETS Nichicon Capacitors	Grow Your Gaming World with Aura Sync Up your game with complementary Aura Sync‑enhanced aesthetics, featuring preset lighting effects that can be easily synchronized across compatible ROG graphics cards, monitors, mice and keyboards to give your setup a unified look.
