Features :
- 4 CH, 1SATA
- Supports AHD/TVI/CVI/CVBS /IP Cameras
- Supports AHD/TVI Cameras upto 2MP
- Supports H.264+/H.264
- Supports Smart Playback & Analytics
- Supports 2 extra IP ch
- Supports 3G/4G Wi-Fi
- Google drive & Dropbox Cloud Storage
Specification
| VIDEO & AUDIO INPUT | |
| Video Input | 4ch BNC interface (1.0Vp-p, 75 Ω) |
| TVI / CVI /AHD | 1080P, 720P |
| IPC | Up to 6ch 2MP |
| Audio Input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Two way Talk | 1-ch, multiplex with Audio Input (RCA) |
| VIDEO & AUDIO OUTPUT | |
| HDMI | 1ch, resolution: 1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz |
| VGA | 1ch, resolution: 1920×1080/60Hz,1280×1024/60Hz,1280×720/ 60Hz,1024×768/60Hz |
| CVBS output | NA |
| Audio Output | 1-ch, RCA (Linear, 1kΩ) |
| RECORDING | |
| Compression | H.264/H.264+ |
| Resolution | Recording in priority: 4ch 1080P lite/960H1/D1/CIF real time |
| Frame Rate(fps) | 1fps-25fps (PAL) / 30fps (NTSC) |
| Video Bit Rate | 11Kbps-2707Kbps |
| Record Mode | Manual, Schedule, Alarm |
| Audio Compression | G.711a |
| Audio Bit Rate | 64Kbps |
| PLAYBACK & BACKUP | |
| Playback Mode | Smart Playback/Normal/Time Division/ Label/ Event/ Picture Playback |
| Playback Rate | 4ch Playback |
| Backup Mode | USB Device/Network |
| SMART FUNCTION | |
| Smart Detection for Analog | 1CH line crossing detection, area Intrusion |
| Smart Playback for Analog | line crossing detection, area Intrusion |
| Cloud Storage | Support |
| Cloud Upgrade | Support |
| NETWORK | |
| Ethernet | 1 RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Network Function | HTTPs,HTTP,TCP/IP,IPv4,UPnP,Onvif2.6,RTSP,RTCP,UDP,SMTP,SNMP,Multicast,IGMP,NTP,DHCP,DNS,DDNS, FTP, P2P |
| Smart Phone | IOS (iPhone, iPad), Android (Phone, Pad) |
| HARD DISK | |
| SATA | 1 HDD |
| Capacity | Up to 8TB capacity for each HDD |
| EXTERNAL INTERFACE | |
| Serial Interface | NA |
| USB Interface | 2 × USB |
| GENERAL | |
| Power Supply | DC12V, 1.5A |
| Power Consumption | ≤10W (without HDD) |
| Working Environment | -10°C~+55°C / 10%~90%RH |
| Dimension (W×D×H) | 250 x 230 x 45mm |
| Weight (without HDD) | 1.5kg |
| Certification | CE, BIS |
| SYSTEM MANAGEMENT | |
| Mobile Software | D-Link Smart CCTV App |
| Desktop Software | DSVS (D-Link Smart Video Surveillance) |
