Features & Benefits Of EATON 9390 Uninterruptible Power Supply System (UPS)
- Proprietary Energy Saver System delivers 99 percent efficiency without sacrificing reliability
- Optimum generator sizing, PFC power supply compatibility, and low THD enhances compatibility with upstream systems for stronger power performance
- Powerware Hot Sync paralleling, superior battery management, and inherent redundancy ensure highest levels of reliability
- Scalable architecture can adapt to future increased power requirements
- Superior control and connectivity for robust manageability
- Fully compatible with the Intelligent Power Software Suite, which offers free monitoring, management, and shutdown software to protect both physical and virtual machinery
Product Snapshot
UPS RATING (0.9 POWER FACTOR) |
|---|
| kVA | 20 / 30 / 40 / 50 / 60 / 80 / 100 / 120 / 160 |
| kW | 18 / 27 / 36 / 45 / 54 / 72 / 90 / 108 / 144 |
| Efficiency | Up to 98% High-efficiency mode, Up to 92% Double-conversion |
GENERAL |
|
| Efficiency | Up to 94%>99% with Energy Saver System |
| Parallel capability | 6x modules w/o tie cabinet; 8x with tie cabinet |
| Audible noise | 65 dBA @ 1 meter |
| Altitude (max) | 2000m at 40??C , 104??F |
ELECTRICAL INPUT |
|
| Voltage | 208, 380, 400, 415, 480, 6002 |
| Voltage range | +10% / -15%3 |
| Frequency range | 55-65 Hz |
| Power factor | 0.99 (min) |
| Input current distortion | 4.5% (no input filter required) |
| Soft start capability | Yes |
| Internal backfeed protection | Yes |
| Broadcast global support | Yes |
