Product Details
If you run a high-volume retail business and you need a barcode scanning solution that elevates checkout throughput, improves the customer experience, and enables you to better execute your mobile marketing programs, the Solaris 7980g Area-Imaging Vertical Slot Scanner is up to the task.
With its compact, modern design and powerful imaging capabilities, the 7980g scanner fits easily into existing enclosures used in retail checkout environments, including convenience, drug, specialty, liquor and grocery stores.
The Solaris 7980g features Honeywell’s Adaptus 6.0 area-imaging technology. You’ll get exceptional scanning performance on 1D and 2D barcodes and even be able to read smartphone screens, digital wallets and printed identification cards.
Omni-directional scanning capability – along with an extended depth of field and advanced decoding software – equips your cashiers to scan virtually all barcodes on the first pass with minimal concern for orientation or barcode print quality.
Do you anticipate the need to read 2D codes in the future, but don’t need that capability today? You can buy the 7980g scanner as an omnidirectional 1D scanner. Then affordably upgrade it to a full 2D area-imager when you’re ready. It’s no longer necessary to buy new scanners when your data capture needs evolve. The Solaris 7980g scanner grows with your business.
With its compact, modern design and powerful imaging capabilities, the Solaris 7980g fits easily into existing enclosures used in high-volume retail checkout environments such as convenience, drug, specialty, liquor and grocery stores. And you can buy the 7980g device as an omnidirectional 1D scanner. Then affordably upgrade it to a full 2D area-imager when you’re ready.
Powerful Imaging Capabilities
Exceptional scanning performance on 1D and 2D barcodes, plus the ability to read smartphone screens, digital wallets and printed identification cards.
Soft, White LED Illumination
Eliminates glare without compromising performance.
Easy to Use
Features a capacitive touch button and intuitive LED indicators that face the user. And you can connect a handheld scanner via a multi-function USB auxiliary port.
Draws Power from the Host
Draws power directly through USB, eliminating the need for an additional power supply and cabling.
|
ELECTRICAL |
|
|
Scanner Unit |
|
|
Input Voltage |
5.0 to 5.2 V (not including auxiliary scanner) |
|
Operating Current: |
400mA (not including auxiliary scanner) |
|
Standby Current |
270mA (not including auxiliary scanner) |
|
Sleep Mode Current |
210mA (not including auxiliary scanner) |
|
Power Supply (sold separately) |
Input Voltage: 100 – 240V/50 – 60HZ |
|
Output Current: 5.2V / 1.0 A |
|
|
Host System Interfaces |
USB, Keyboard Wedge, RS232, IBM 46xx (RS485) |
|
ENVIRONMENTAL |
|
|
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
|
Storage Temperature |
-20°C to 60 °C (- 4°F to 140°F) |
|
Humidity |
5% to 95% relative humidity, non-condensing |
|
Environmental Sealing |
IP5X |
|
Light Levels |
100,000 lux |
|
SCAN PERFORMANCE |
|
|
Scan Pattern |
Area image (1280 x 960 pixel array) |
|
Motion Tolerance |
13mil at optimal focal point |
|
Scan Angle: |
Horizontal: 42°; Vertical: 34° |
|
Print Contrast: |
25% minimum reflectance difference |
|
Pitch, Skew |
+/-65°, +/-75° |
|
MECHANICAL |
|
|
Dimensions (HxWxD) |
148 mm x 152 mm x 85 mm (5.83 in x 5.98 in x 3.35 in) |
|
Weight |
527 g (19 oz.) |
